304 316L Mirror Finish Multi Bag Filter Housing For Chemical Water Oil Filtration Plant

Product Features

Full mirror-polished structure
The inner and outer walls of the cylinder achieve mirror-like luster, without dead corners or weld seam accumulation, significantly reducing the risk of medium residue and facilitating quick cleaning and batch switching.

Multi-bag parallel design
It adopts a parallel filter bag installation method, with uniform flow distribution and low pressure difference. A single equipment can achieve continuous large-flow filtration, reducing the equipment’s floor space.

Quick-opening sealing mechanism
Standardly equipped with suspended or clamp-type quick-opening covers, combined with O-ring/silicone seals, the filter bag replacement can be completed without tools, and the single-person operation time is no more than 5 minutes.

Full exhaust bottom valve and exhaust valve
The bottom is equipped with a large-flow discharge port, and the top has an automatic/manual exhaust valve, effectively avoiding air blockage and ensuring the stable operation of the filtration process.

Optional heating/insulation jacket
For high-viscosity or low-temperature prone to crystallization materials, steam or electric heating jackets can be added to maintain the optimal working temperature of the medium.

Product advantages

Hygienic surface quality
Mirror surface treatment not only enhances the appearance texture, but also significantly reduces the growth of microorganisms and chemical corrosion points, meeting the strict requirements of food, beverage and fine chemical industries for contact materials.

Low energy consumption and low material cost
The optimized fluid dynamics design reduces the pressure drop by 15% to 20% compared to traditional welded filters, while improving the filter bag utilization rate and extending the single replacement cycle.

Extremely strong corrosion resistance adaptability
316L material is available, combined with the mirror-like passivation layer, it can withstand salt spray, weak acids, alkalis and organic solvents, and is suitable for marine engineering and electroplating fluid circulation filtration.

Flexible modular expansion
The inlet and outlet flanges can be customized according to ANSI/DIN/JIS standards and can be connected in series or in parallel to the existing pipeline system without modifying the main process pipeline.

Safe interlock protection
Built-in anti-loosening filter bag retaining ring and mechanical safety latch prevent filter bag displacement or accidental opening of the cover under high-pressure conditions.

Application fields
Fine chemicals: production cycle filtration of coatings, inks, resins, adhesives, surfactants

Electronic materials: fine filtration of etching solutions, cleaning solutions, chemical mechanical polishing (CMP) slurries

Food and beverages: impurity removal treatment of edible oil, juice, syrup, brewing water and seasonings

Industrial water treatment: cooling circulating water, wastewater reuse pre-treatment, pre-filtering of membrane systems

Marine and offshore engineering: ballast water filtration, fuel/air lubrication system purification

Metal processing: recycling filtration of rolling liquids, cutting fluids, cleaning solvents
