SS304 7 Bag Filter Vessel DN250 Side In Bottom Out 1.6MPa for Liquid Filtration

Product features

1.A 7-bag parallel structure is adopted, enabling high-flow filtration with a single unit, reducing the floor space required.

2.The shell is made of SS304 stainless steel with a wall thickness of 5.0mm, featuring high structural strength and excellent corrosion resistance.

3.The design pressure is 1.6MPa, and the working pressure is 1.0MPa, meeting the requirements of conventional industrial pipeline pressure.

4.The flow direction is side entry and bottom exit, facilitating pipeline layout and filter bag replacement operations.

5.The inlet and outlet use DN250 (ISO) standard flanges, with standardized connections and strong adaptability.

6.The surface is sandblasted for enhanced appearance texture and weather resistance.

7.It is compatible with Ø180×810mm specification PP filter bags, with a 100-micron precision, easy replacement, and controllable operating costs.

8.It is suitable for temperatures ≤80℃, covering most normal temperature liquid filtration conditions.

Product advantages

1.High-flow design: The 7 bags are configured to provide a larger effective filtration area under the same shell volume, suitable for continuous high-flow operations.

2.Reliable structure: With a 5.0mm wall thickness and a design pressure of 1.6MPa, it ensures the equipment can operate stably for a long time under a working pressure of 1.0MPa.

3.Wide material applicability: SS304 has good tolerance for various neutral and weakly corrosive liquids, extending the equipment’s service life.

4.Efficient maintenance: The side-in, bottom-out structure combined with standard filter bag sizes enables a single person to complete the filter bag replacement, reducing downtime.

5.Standardized interfaces: DN250 (ISO) inlet and outlet are convenient for connecting with existing pipeline systems, reducing renovation costs.

Application fields

1.Industrial circulating water filtration

2.Coolant and cleaning fluid filtration

3.Pre-treatment and circulating filtration of electroplating solutions

4.Chemical raw material liquid filtration

5.Coating and ink filtration

6.Liquid clarification and impurity interception in the food and beverage industry (non-direct contact type)

7.Other industrial liquid processing scenarios requiring large flow rates and 100-micron solid-liquid separation

Product selling points

1.7 large-flow bags, with at most one main unit, saving pipelines and floor space.

2.SS304 stainless steel housing, 5.0mm wall thickness, with a pressure-bearing capacity of 1.6MPa, durable and reliable.

3.Side inlet and bottom outlet + DN250 standard interface, facilitating installation and maintenance with less effort.

4.Suitable for Ø180×810mm PP filter bags, with a precision of 100 microns, having strong versatility for consumables.

5.Sandblasted surface treatment, balancing appearance and corrosion resistance.

6.Suitable for large-flow filtration needs of various industrial liquids below 80℃.
