Brief Introduction:

This equipment is an 870 type box-type filter press. It adopts a one-time opening discharge mechanism and is equipped with a mechanical vibrating screen system.The entire frame of the machine is wrapped with stainless steel.This model is specifically designed for small and medium-sized filtration area requirements, combining rapid discharge with corrosion-resistant structure.It is suitable for solid-liquid separation processes in industries such as chemical, food, environmental protection, and mineral processing.

Download as PDF

Product Detail

Product Features






1.Integrated vibrating plate system:
Each filter plate or the plates in intervals are equipped with a vibrating device. During discharging, they will vibrate automatically to assist in the detachment of the filter cake, thereby reducing the frequency of manual cleaning.
2.One-time pulling structure:
The hydraulic drive enables the simultaneous pulling of all filter plates, resulting in a fast discharging speed and a significant improvement in efficiency compared to the traditional method of pulling each plate one by one.
3.Frame stainless steel enclosure:
The exterior of key steel structures such as the main beam, cylinder base, and tail plate is covered with stainless steel plates to prevent exposure to corrosive environments.
4.Box-type filter plate:
Made of reinforced polypropylene filter plates, it has excellent sealing performance and stable filtration pressure.

Product advantages









1.High corrosion resistance:
The stainless steel coating effectively protects the frame from the erosion caused by acids, alkalis, salt fog and high humidity environments, thereby extending the overall service life of the equipment.
2.Discharge is cleaner:
The vibrating plate system breaks the adhesion between the filter cake and the filter cloth, especially having a remarkable effect on removing the filter cake from viscous materials, and reducing filter cloth blockage.
3.Low maintenance cost:
The one-time opening mechanism has a compact structure. The vibration plate component is independent and easy to replace, and the stainless steel coating layer is easy to clean.
4.High production continuity:
The single plate removal cycle is short, making it suitable for continuous feeding operation scenarios.
5.Compliant with food-grade factory hygiene standards:
The stainless steel packaging meets the hygiene requirements for food, beverages, and some fine chemical workshops.

Application fields
1


Chemical industry: Filtration of pigments, dyes and other slurries.


2


Environmental protection and water treatment: Industrial wastewater sludge dewatering, river dredging, electroplating sludge, and printing and dyeing sludge reduction treatment.


3


Food and beverages: Juice clarification, starch dehydration, plant extract filtration, wine coarse filtration.


4


Minerals and Metallurgy: Concentrate tailings slurry, ceramic slurry, kaolin dehydration, metal hydroxide filtration.


5


Biology and Fermentation: Amino acids, enzyme preparations, organic acid fermentation broth solid-liquid separation.


Company Profile
 公司介绍1
公司介绍2
3
FAQ

Q: Are you manufacturer?
A: Yes. We are experienced manufacturer of filter equipment.
Q:What products you provide?
A: We produce more than 200 different models of the filter. The main products are the Press Filter/Bag Filter Housing/Automatic self cleaning filter/Basket filter/Magnetic filter/ Candle filter/Leaf filter/Cartridge filter housing/Filter Plate/Filter Cloth/Filter Cartridge /Filter Bag, also matched tanks, conveyors, etc.
Q: How to select the type you needed?
A: We will ask you some information: solid liquid kind, usage, flow rate, solid content
percentage, working temperature & pressure, etc. We have professional technical team which will work together with our sales to help you choose the suitable machine for you.
Q. Is it easy to operate for the new user ?
R. A: Yes. We offer you manual book and operating video. When you have any questions during using, we will answer you within 24 hours. For large projects, we can also send our engineers to your site for commissioning and training.
Q: What’s MOQ?
A: 1 PCS.
Q: Do you accept OEM?
A: Yes.
Q:Quality Warranty.
A:12 months after the installation and commission or 18 months after it has been delivered to the site of the customer.
