Industrial Sludge Dewatering Filter Press 630x630mm Enhanced PP Filter Plates 30mm Cake Thickness

Industrial Sludge Dewatering Filter Press 630x630mm Enhanced PP Filter Plates 30mm Cake Thickness Featured Image
  • Industrial Sludge Dewatering Filter Press 630x630mm Enhanced PP Filter Plates 30mm Cake Thickness
  • Industrial Sludge Dewatering Filter Press 630x630mm Enhanced PP Filter Plates 30mm Cake Thickness
  • Industrial Sludge Dewatering Filter Press 630x630mm Enhanced PP Filter Plates 30mm Cake Thickness
  • Industrial Sludge Dewatering Filter Press 630x630mm Enhanced PP Filter Plates 30mm Cake Thickness
  • Industrial Sludge Dewatering Filter Press 630x630mm Enhanced PP Filter Plates 30mm Cake Thickness
  • Industrial Sludge Dewatering Filter Press 630x630mm Enhanced PP Filter Plates 30mm Cake Thickness

Brief Introduction:

This model is a box-type filter press that features automatic hydraulic pressing and manual plate pulling. It is suitable for solid-liquid separation in industries such as chemical, environmental protection, food, and metallurgy. The design with central feeding and concealed liquid discharge prevents material splashing, ensuring a cleaner working environment.


Download as PDF

Product Detail

Product Features

1.Manual plate pulling:
Simple structure, low failure rate, suitable for small and medium batch production or intermittent operations.
2.Central feed:
The materials enter each filter chamber uniformly through the central holes of the filter plates, resulting in uniform cake formation and high filtration efficiency.
3.Enhanced PP filter plate:
Corrosion-resistant, resistant to certain temperatures, lightweight, and highly sealed.
4.Carbon steel frame:
Fully welded or bolted connection, with high strength and long service life.
5.Internal leakage liquid:
The filtrate is centrally discharged through internal channels, suitable for the closed treatment of odorous, volatile or toxic materials.
6.Automatic hydraulic clamping:
The hydraulic station automatically provides high-pressure clamping force, ensuring excellent sealing performance and preventing material leakage.
Product advantages
1.High pressure adaptability:
The inlet pressure is 0.6 MPa, suitable for most medium-viscosity and fine-particle materials.
2.Controllable filter cake thickness:
30mm filter cake thickness, facilitating subsequent cake removal and washing operations.
3.Low maintenance cost:
Manual plate pulling reduces the wear of automated components, and the hydraulic system is stable and reliable.
4.High environmental friendliness:
The submerged flow structure prevents leakage at the site, meeting the requirements of clean production in factories.
Application fields
1
Chemical industry: Pigments, dyes, titanium dioxide, fine chemical intermediates filtration
2
Environmental Protection Engineering: Dewatering of industrial wastewater, electroplating sludge, and river sediment
3
Food processing: Extraction of plant liquids, juice, starch, and oil filtration
4
Metallurgy and Mineral Processing: Tailings dewatering, concentrate filtration
5
Non-metallic minerals: Kaolin, bentonite, calcium carbonate dehydration
Parameter Table
Company Profile
1
2
3
FAQ
Q: Are you manufacturer?
A: Yes. We are experienced manufacturer of filter equipment.
Q:What products you provide?
A: We produce more than 200 different models of the filter. The main products are the Press Filter/Bag Filter Housing/Automatic self cleaning filter/Basket filter/Magnetic filter/ Candle filter/Leaf filter/Cartridge filter housing/Filter Plate/Filter Cloth/Filter Cartridge /Filter Bag, also matched tanks, conveyors, etc.
Q: How to select the type you needed?
A: We will ask you some information: solid liquid kind, usage, flow rate, solid content
percentage, working temperature & pressure, etc. We have professional technical team which will work together with our sales to help you choose the suitable machine for you.
Q. Is it easy to operate for the new user ?
R. A: Yes. We offer you manual book and operating video. When you have any questions during using, we will answer you within 24 hours. For large projects, we can also send our engineers to your site for commissioning and training.
Q: What’s MOQ?
A: 1 PCS.
Q: Do you accept OEM?
A: Yes.
Q:Quality Warranty.
A:12 months after the installation and commission or 18 months after it has been delivered to the site of the customer.
