Stainless Steel 4 Bag Filter Housing for Paint Ink Coating Filtration 2# Bags 10 Micron

Stainless Steel 4 Bag Filter Housing for Paint Ink Coating Filtration 2# Bags 10 Micron Featured Image
  • Stainless Steel 4 Bag Filter Housing for Paint Ink Coating Filtration 2# Bags 10 Micron
  • Stainless Steel 4 Bag Filter Housing for Paint Ink Coating Filtration 2# Bags 10 Micron
  • Stainless Steel 4 Bag Filter Housing for Paint Ink Coating Filtration 2# Bags 10 Micron
  • Stainless Steel 4 Bag Filter Housing for Paint Ink Coating Filtration 2# Bags 10 Micron
  • Stainless Steel 4 Bag Filter Housing for Paint Ink Coating Filtration 2# Bags 10 Micron
  • Stainless Steel 4 Bag Filter Housing for Paint Ink Coating Filtration 2# Bags 10 Micron

Brief Introduction:

This JYMF-4P-304 type stainless steel multi-bag filter is made of high-quality SS304 stainless steel and is equipped with 4 filter baskets, allowing for the simultaneous installation of 4 2# standard filter bags.The equipment adopts a lateral inlet and bottom outlet fluid path, and is compatible with DN80 ASME B16.5 flange interfaces.It is specially designed for large flow precision filtration of medium and low viscosity liquids. Its working pressure reaches 1.0 MPa and is widely applicable to the clarification filtration of various water-based liquids, oils, and chemical solvents.

Download as PDF

Product Detail

Product Features
1.Multi-bag structure:
Standardly equipped with 4 SS304 filter baskets, supporting parallel filtration of multiple bags. The single machine processing capacity is large, reducing the equipment footprint.
2. High-quality materials:
The entire machine and the filter basket are made of SS304 stainless steel and undergo sandblasting treatment. The surface is uniformly matte, corrosion-resistant and easy to clean.
3. Reliable sealing:
Utilizing the EPDM (Ethylene Propylene Diene Monomer) sealing material, it exhibits excellent heat resistance, resistance to weak acids and alkalis, and aging resistance under a working temperature range of 40-45℃.
4. Standard filter bag compatibility:
Compatible with 180×810mm (2#) filter bags, made of PP material, with a 10-micron precision, steel ring mouth design, ensuring stable installation without falling off.
5. Convenient interface:
The DN80 flange complies with the ASME B16.5 standard and is compatible with the pipeline system easily. The side-entry bottom-out structure facilitates thorough emptying and drainage.

Product advantages
1. High flow rate:
The four-bag parallel design significantly increases the single-pass filtration flow rate, making it suitable for continuous production lines.
2. Low maintenance cost:
Only the filter bags need to be replaced. The filter basket can be reused. The spare filter bags can be used immediately upon replacement, resulting in short downtime.
3. Stable structure:
With a design pressure of 1.0 MPa, it can withstand normal process fluctuations and meets the filtering requirements of most industrial liquids.
4. Excellent compatibility:
The PP filter bags have excellent chemical resistance and are suitable for non-strongly corrosive liquids such as water treatment, electroplating solutions, coatings, inks, and food additives.

Application fields



1


Industrial water treatment: such as cooling circulating water, RO pre-treatment, and cleaning water reuse filtration.


2


Fine chemicals: Filtration of solvents, resins, adhesives, surfactants, etc.


3


Food and beverages: Syrup, vegetable oil, seasonings, and alcohol clarification and filtration (in compliance with food contact material requirements).


4


Electronics and electroplating: Removal of particulates from electroplating solutions, etching solutions, and cleaning solvents.


5


Petroleum and lubricants: Base oil, additives, cutting fluid, hydraulic oil filtration.


Parameter Table

Customer review



Company Profile
公司介绍1
2
3
FAQ

Q: Are you manufacturer?
A: Yes. We are experienced manufacturer of filter equipment.
Q:What products you provide?
A: We produce more than 200 different models of the filter. The main products are the Press Filter/Bag Filter Housing/Automatic self cleaning filter/Basket filter/Magnetic filter/ Candle filter/Leaf filter/Cartridge filter housing/Filter Plate/Filter Cloth/Filter Cartridge /Filter Bag, also matched tanks, conveyors, etc.
Q: How to select the type you needed?
A: We will ask you some information: solid liquid kind, usage, flow rate, solid content
percentage, working temperature & pressure, etc. We have professional technical team which will work together with our sales to help you choose the suitable machine for you.
Q. Is it easy to operate for the new user ?
R. A: Yes. We offer you manual book and operating video. When you have any questions during using, we will answer you within 24 hours. For large projects, we can also send our engineers to your site for commissioning and training.
Q: What’s MOQ?
A: 1 PCS.
Q: Do you accept OEM?
A: Yes.
Q:Quality Warranty.
A:12 months after the installation and commission or 18 months after it has been delivered to the site of the customer.
