316L SS Single Bag Filter Liquid Filtration 1um PP Filter Bag

Brief Introduction:

This product is a single-bag type filter made of 316L stainless steel.It is compactly designed and structurally sound, suitable for precise filtration of seawater and normal temperature liquids, etc. The standard filter bag is made of PP material (1 micron, 304 steel ring), and is widely used in industrial processes that require high filtration accuracy and corrosion resistance.

Send email to us Download as PDF

Product Detail

Product Features

1.316L stainless steel material:

resistant to corrosion, seawater and oxidation, suitable for demanding working conditions.

2.Precise filtration:

Standardly equipped with 1-micron PP filter bags, effectively intercepting tiny particulate impurities.

3.Flange connection method:

The inlet and outlet ports are DN80 flanges, in accordance with ANSI 150# standards, and the installation is convenient.

4.Sealing performance is reliable:

The fluorine rubber sealing ring is resistant to heat and oil, and has excellent sealing properties.

5.With sewage discharge function:

The bottom sewage discharge pipe is equipped with a bend, which is convenient for cleaning and maintenance.

6.Surface polishing treatment:

Both the inner and outer surfaces are polished to reduce material residue and make cleaning easier.

Product advantages

1.Design pressure is high:

1.6 Mpa, suitable for high-pressure conditions.

2.Adaptable:

Capable of handling various media such as seawater, chemical liquids, and water treatment fluids.

3.Compact structure:

The filter has a diameter of 219mm, with a small footprint and easy integration.

4.All accessories are complete:

It can be paired with 316 ball valves, connectors, covers, etc., enhancing the integrity of the system.

Parameter Table

Application fields

1.Seawater pretreatment and filtration

2.Chemical liquid filtration

3.Fine chemicals, food industry

4.Water treatment, environmental protection engineering

5.Precision filtration system for industrial liquids
